M852

OIL-OIL BOOSTER

– n. 3 pressure ratio
– hydraulic pressure: up to > 4.000 Bar

Hydraulically controlled double-acting oil-oil booster, used to generate static or pulsed pressures up to 4000 bar.
M852 boosters are constructed from top- quality materials, chromed H.P: piston combined with special seals, which guarantee a large number of duty cycles.
What’s more, these boosters are able to work with two different uids: one for the L.P. intake and the other for the H.P. delivery side. Special seals are tted depending on the liquid used in service.

Main Applications:

• Powder metallurgy.
• Test rigs for resistance and explosion tests on regulator and calibrator devices

Download:
DATA SHEET     |    2D TECHN. DRAWS    |    3D TECHN. DRAWS
